Hydropower Plant Stegenwald

A new design for a hydropower plant at a long-discussed location on the Salzach River in Austria requires cost savings and the minimisation of building space in a sensitive natural area to obtain a permit for construction.

In order to realise a reduction in the overall width of the power plant, the idea was born to turn a classic vertical Kaplan turbine with a concrete semi-spiral case by 90 degrees horizontally and to replace the elbow-type draft tube with a straight draft tube. At present, the inflow passes downwards via a horizontal screen into the specially shaped concrete spiral.

To save construction depth, the unconventional spiral was designed in accordance with the idea of a pump intake sump. In the event of a flood, the weir installed above the turbine downstream of the screen can release additional water to the tailwater. …

Der Fachartikel ist nur in englischer Sprache verfügbar.

Autoren

Helmut Benigni, Vice-head of the Institute of Hydraulic Fluid Machinery, Graz University of Technology

Jürgen Schiffer, Managing Director of Prof. Dr. Jaberg & Partner GmbH

Gerhart Penninger, Head of the Department for Mechanical Engineering and Hydraulic Steelwork, Verbund Hydro Power GmbH

Hannes Badura, Hydraulic Engineer and Project Manager at Verbund Hydro Power GmbH

Christian Witti, Lead Engineer Kaplan and Project Engineer for Stegenwald, Global Hydro Energy GmbH

Markus Pühringer, Hydraulic Design and Power Plant Project Planning, Global Hydro Energy GmbH
